Large Capacity 6000PCS / H Automatic Egg Box Carton Making Machine
The egg box production line is made up of several working systems:
pulping system, forming system, drying system, collection system.
Working system contains many components and equipment, like
hydra-pulper, vibration screen, sewage pump, refiner, air
compressor, egg box forming machine, vacuum pump, egg box dryer,
burner, stacker, etc.
Thereinto, the egg box forming machine and egg box dryer are main
parts of egg box production line, all the casting of these two
parts are precision machined, and all parts contact with water are
304#stainless steel material, which can increase the equipment
durability. All the brand of auxiliary equipment is the top brand
in their respective fields.
There will be several different investment scales that can be
chosen by customers, some of the most popular choices are
2000pcs/h, 3000pcs/h, 4000pcs/h, 6000pcs/h egg box production line.
Usually, the production throughput measuring basis is according to
12-cell egg box, and the egg box production line can also
produce other products types, like 4-cell egg box, 6-cell egg box,
9-cell egg box, 10-cell egg box, 15-cell egg box, 18-cell egg box,
30-cell egg tray and so on, the corresponding production throughput
should according to the exact size of real samples.
Specification of egg box machine
| Item | Information | Notes |
| Output Range | 6000pcs/h | 30 packed egg tray(60~80g) |
| Workshop recommendation | ≥600m2 | Length≥40m;Width≥15m;Height≥6m; (It could be adjusted according to the user's existing workshop) |
| Type of Material | Waste paper | Newspaper/Carton /Paper box/Books/ Corrugated paper/Kraft paper etc. |
| Material consumption | 360~480kg/h | 30 packed egg tray(60~80g) |
| Water consumption | 800-1050kg/h | 30 packed egg tray(60~80g) |
| Electricity consumption | 140-175kw/h | Full throttle operation |
Fuel consumption (approximately) | LPG 55~70 kg/h | 30 packed egg tray(60~80g) Choose one from these types of fuel |
| Natural gas 85~100 m3/h |
| Diesel 65~80kg/h |
| Operator Required | 5~8 person/shift | 24hours, 3shift |
| Container requirement for Transport | 5 of 40 HQ container + 1 of 20’GP container | Whole production line |
The whole production line include pulp making system + egg tray
molding system + egg tray drying system + egg tray packing system.
1. )Pumping system
To smash the water paper to pulp.
Hydrapulper, Pulp pump, Air compressor, agitator, Self priming
pump, pulping machine.
2. )Molding System
Produce the paper mold finished products
Full automatic egg tray forming machine, Vacuum pump, High pressure
washer, Negative pressure tank, mould, Transfer mould, baler.
3. )Drying systerm
Multi Layer Metal Drying
High efficient, Goes into production fastly, short install time,
Less plant area required
We adopt metal multi-layer drying line, direct combustion hot air
circulation. Using the imported or joint venture brand burner
(domestic uses the stove bar), equipped with an automatic control
cabinet.
4). Auto stacking packing machine
